Electric seated reach truck CQD15X-45

The Chinlift has launched a new type of seated reach truck CQD15X-45 models, after careful design and improvement. This model has the traditional advan­tages of a reach truck such as high load, high lifting, and narrow aisle, and has made great improvements in efficiency and vision. Compared with the existing models on the market, it has achieved obvious advan­tages, especially driving speed, lifting speed, lowering speed and mast stability. Using this model can improve the efficiency and utilization of your ware­house.

  • Model :

    CQD15X-45
  • Power Type :

    Electric
  • Load Capacity :

    1500kg
  • Lifting Height :

    3300-8000mm
  • Description

Electric seated reach truck CQD15X-45



The Chinlift has launched a new type of seated reach truck CQD15X-45, after careful design and improvement. This model has the traditional advan­tages of a reach truck such as high load, high lifting, and narrow aisle, and has made great improvements in efficiency and vision. Compared with the existing models on the market, it has achieved obvious advan­tages, especially driving speed, lifting speed, lowering speed and mast stability. Using this model can improve the efficiency and utilization of your ware­house.

  • Electric seated reach truck CQD15X-45
  • Electric seated reach truck CQD15X-45
  • Electric seated reach truck CQD15X-45



Features:

  • Compact structure, high maneuverability. Low gravity center with good stability. It suits large tonnage, high lifting goods storage scenarios.
  • lt features in overall mast moving forward, with small turning radius to neglect obstacles at the bottom of the racks. It suits any space-Iimited scenarios, easy loading or unloading goods.
  • Equipped with fu II AC drive system, small volume, light weight,high efficiency, free-maintenance and carb on-bru sh replacement. No more maintenance and protection;
  • Standard forks tilting up or down function, prevents goods from tipping over and improving the load capability.
  • Side-pull battery suits multi-shifing occasions, with standard roller trolley for easy change;
  • 6.5m or above high-strength H type mast steel, not easy to deform, it's reliable and stable operation.

Technical Specifications (Product Information)



Model CQD15X-45
Power type Electric
Work type Side-standing
Rated capacity 1500kg
Load center 500mm
Wheel base 1562mm
Mast lifting height 4500mm
Mast extended height 5585mm
Mast lowered height 3050mm
Overhead guard height 2280mm
Overall length (with fork) 2410mm
Overall width 1390mm
Fork size 35/100/1070mm
Min. ground clearance 65mm
Aisle Width for Pallet 1000*1200 crossways 2835mm
Min. turning radius 1854mm
Max.travelling speed,unladen/loaded 7/6.5km/h
Service brake Electromagnetic
Battery capacity 48V600Ah
Drive motor 4.5kW AC
Lifting motor 7.5kW AC
Self weight 3650kg

Customizable Options

Camera

Optional

Li-ion battery

Optional

Side shift

Optional

Colors

Customized accepted
