Mini Order Picker FOP3/4

The Chinlift electric order picker FOP3/4 is a type of double mast self-propelled aerial work platform that can improve your working efficiency and enhance productivity in the workplace. The compact structure and small size of this vertical mast lift make it easy to set up and pass through narrow aisles and doorways, offering a great convenience to your outdoor or indoor applications such as warehousing, inventory management, transporting, stock-picking etc.

  • Model :

    FOP3/4
  • Power Type :

    Electric
  • Load Capacity :

    150+90kg
  • Lifting Height :

    3000/4000mm
  • Description

Electric Order Picker FOP3/4



The Chinlift electric order picker FOP3/4 is a type of double mast self-propelled aerial work platform that can improve your working efficiency and enhance productivity in the workplace. The compact structure and small size of this vertical mast lift make it easy to set up and pass through narrow aisles and doorways, offering a great convenience to your outdoor or indoor applications such as warehousing, inventory management, transporting, stock-picking etc.

  • 3 Ton Diesel Counterbalance Forklift



Features:

  • Light weight design, Stable, Simple operation.
  • Suitable for warehouse, supermarket and other narrow space environment.
  • Fault diagnosis, oil pipe explosion -proof system.

Technical Specifications (Product Information)



Model FOP3 FOP4
Power type Electric
Work type Stand-on style
Rated capacity For Person 150kg 150kg
For Goods 90kg 90kg
Max. platform height 3000mm 4000mm
Max. working height 4125mm 5125mm
Work platform size For Person 695×720mm 695×720mm
For Goods 550×740mm 550×740mm
Min. turning radius 1700mm
Max. climing capacity 5°-8°mm
Drive motor 24V/0.5×2kW
Lifting motor 24V/0.8kW
Battery capacity 2×12V/100Ah
Overall length 1480mm
Overall width 756mm
Overal height 1475mm 1850mm
Self weight 840kg 870kg



Customizable Options

Warning light

Optional

Li-ion battery

Optional

Lifting height

Optional

Colors

Customized accepted
